Waste Truck Dongfeng 4×2 – We Engineer Transport Vehicles to Power Global Logistics

Description

The Dongfeng Tianjin Series 18-Foot Compressible Waste Truck, featuring a Tier 3 emission-compliant chassis, combines sleek aesthetics with exceptional cost-effectiveness, safety, and user-friendly operation. As our company’s proven product, it incorporates a fully enclosed system comprising a sealed waste compartment, loading mechanism, push shovel, hydraulic transmission, and electronic control panel. Utilizing integrated electro-hydraulic technology, the vehicle employs a coordinated mechanical-electrical-hydraulic control system. Through specialized components including the waste compartment, loading mechanism, and push shovel, it achieves comprehensive waste processing: compacting, crushing, and securely filling waste into the compartment. All wastewater generated during compression is channeled into a dedicated drainage compartment, effectively addressing secondary pollution risks in waste transportation.

Product chassis configuration and upper mounting manufacturing standards and special requirements

Vehicle configuration parameters:
product name		Dongfeng Tianjin compression garbage truck
Body dimensions (length × width × height)		8620×2550×3400
gross mass		18000kg
Rated load capacity		6300kg
curb weight		11700kg
wheel base		5000mm
Approach Angle / Departure Angle		20/16°
Chassis configuration parameters:
Chassis Model		DFL1160BX1V
Cab color		Jade
Drive type		4×2
wheel base		5000mm
engine type		ISB190 (Cummins)
engine power		140kW (Cummins)
Engine horsepower		190 horsepower (Cummins)
gear-box		Fast 8-Beams
effluent standard		State 3
Front/rear axle		5T/10T (Dyna)
tyre		10.00R20 Steel wire tire (7)
else		Air brake, other Dongfeng chassis standard.
Custom configuration parameters:
Effective tank volume		About 18 m³
Box shape		New Arc
Box material		Q345 manganese steel (edge 4 bottom 5)
reduction ratio		≥2.5
Filler effective volume		≥1.3m³
Fill cycle time		≤25s
Loading cycle time		≤15s
Time to dispose of trash		≤35s
control method		Automatic, manual
Hydraulic system pressure		18MPa
multiple directional control valve		Jiangsu Oil Valve
Hydraulic oil pump		Hefei oil pump
hydraulic jack		Jiangsu Cylinder
Converter		Jia Shan, Zhejiang
Electrical Control System (PLC One-Click Cycle)		Taiwan imports
Engine Power Control		full-automatic control
Other dedicated features	1. New type of breakable scraper 2. Bidirectional peristaltic compression function 3. With a central and rear double sewage tank 4. The pusher and slide blocks are made of high-quality MC nylon 5, and the filler lifting cylinder is equipped with a balance valve. 6. High-mounted body trim lights, side lights, and work lights
Flip mechanism (see the figure below)	(1) Bucket-type flip (2) Air-controlled rear cover (3) Small triangular bucket (4) Fully sealed bucket (5) Rear flip swing arm type

Description

Product chassis configuration and upper mounting manufacturing standards and special requirements

Vehicle configuration parameters:

product name

Dongfeng Tianjin compression garbage truck

Body dimensions (length × width × height)

8620×2550×3400

gross mass

18000kg

Rated load capacity

6300kg

curb weight

11700kg

wheel base

5000mm

Approach Angle / Departure Angle

20/16°

Chassis configuration parameters:

Chassis Model

DFL1160BX1V

Cab color

Jade

Drive type

4×2

wheel base

5000mm

engine type

ISB190 (Cummins)

engine power

140kW (Cummins)

Engine horsepower

190 horsepower (Cummins)

gear-box

Fast 8-Beams

effluent standard

State 3

Front/rear axle

5T/10T (Dyna)

tyre

10.00R20 Steel wire tire (7)

else

Air brake, other Dongfeng chassis standard.

Custom configuration parameters:

Effective tank volume

About 18 m³

Box shape

New Arc

Box material

Q345 manganese steel (edge 4 bottom 5)

reduction ratio

≥2.5

Filler effective volume

≥1.3m³

Fill cycle time

≤25s

Loading cycle time

≤15s

Time to dispose of trash

≤35s

control method

Automatic, manual

Hydraulic system pressure

18MPa

multiple directional control valve

Jiangsu Oil Valve

Hydraulic oil pump

Hefei oil pump

hydraulic jack

Jiangsu Cylinder

Converter

Jia Shan, Zhejiang

Electrical Control System (PLC One-Click Cycle)

Taiwan imports

Engine Power Control

full-automatic control

Other dedicated features

1. New type of breakable scraper

2. Bidirectional peristaltic compression function

3. With a central and rear double sewage tank

4. The pusher and slide blocks are made of high-quality MC nylon 5, and the filler lifting cylinder is equipped with a balance valve.

6. High-mounted body trim lights, side lights, and work lights

Flip mechanism (see the figure below)

(1) Bucket-type flip (2) Air-controlled rear cover

(3) Small triangular bucket (4) Fully sealed bucket

(5) Rear flip swing arm type
