Low flatbed semi-trailer

Low flatbed semi-trailer

Category Semi Trailer

Served Globally

0 +

Products Available

0 +

Description

Carrying capacity: 60T

Length*Width*Height (mm) 16500*2550*800

Tires 11.00R20/12.00R20/12R22.5/315/80R22.5/385/65R22.5 (optional) Quantity 12

Wheel rim 8.5-20/9.0-20/9.0-22.5/11.75-22.5 (optional) quantity 12

Car axle (Brand: FUWA/BPW/SAF/MK) 11T,13T,16T,20T (optional based on user requirements) 3 sets Drum brakes

Legs: JOST Single-Action A300 Rear Foldable Legs/FUWA

Toolbox: one below the forehead

Reserve tire rack: 2 at the front

Brake calipers: 6 pairs

Brake valve: WABCO

ABS: WABCO/Comi

JOST drawbar: 2-inch (50mm) or 3.5-inch (90mm)

Suspension system: mechanical suspension / air suspension

The beam height is 500mm, with 20mm upper flange, 25mm lower flange, and 12mm vertical plate.

Vehicle floor: 4mm thick patterned plate

Ladder: Mechanical ladder 1 pair, 850mm width

Low flatbed semi-trailer

Description

Description

Carrying capacity: 60T

Length*Width*Height (mm) 16500*2550*800

Tires 11.00R20/12.00R20/12R22.5/315/80R22.5/385/65R22.5 (optional) Quantity 12

Wheel rim 8.5-20/9.0-20/9.0-22.5/11.75-22.5 (optional) quantity 12

Car axle (Brand: FUWA/BPW/SAF/MK) 11T,13T,16T,20T (optional based on user requirements) 3 sets Drum brakes

Legs: JOST Single-Action A300 Rear Foldable Legs/FUWA

Toolbox: one below the forehead

Reserve tire rack: 2 at the front

Brake calipers: 6 pairs

Brake valve: WABCO

ABS: WABCO/Comi

JOST drawbar: 2-inch (50mm) or 3.5-inch (90mm)

Suspension system: mechanical suspension / air suspension

The beam height is 500mm, with 20mm upper flange, 25mm lower flange, and 12mm vertical plate.

Vehicle floor: 4mm thick patterned plate

Ladder: Mechanical ladder 1 pair, 850mm width

Heavy-duty construction equipment built to withstand the rigors of infrastructure projects.
